EC Twin Screw Extruder
EC-compounder series are specially designed for those users who wish to make small to medium size compounding quantities and less torque inquiry for process. The EC Series machines have the features of easily-maintained, simple operation concept, user-friendly and cost-effective.
The EC-series twin screw extruders have significant PRICE/PERFORMANCE ratio.
Índice de contenidos
Applications
The EC- compounder is designed for a wide range of application in the polymer compounding industry:
- Masterbatches (B material for the XLPE Cable, Additive Masterbatch)
- Nanometre (SiO2/Talc/CC) Compounding
- Devolatilization (PMMA/CPP/K-resin/SBS)
EC Series Specifications
| Modelo | Diámetro (mm) | Max. Velocidad (rpm) | Motor (kW) | Par específico (Nm/cm3) | Producción (kg/hr) |
|---|---|---|---|---|---|
| EC40 | 41 | 600 | 30 | 5.8 | 70-120 |
| EC52 | 51.4 | 600 | 55 | 5.5 | 130-220 |
| EC65 | 62.4 | 600 | 90 | 5.1 | 200-350 |
| EC75 | 71 | 600 | 132 | 4.9 | 400-600 |
| EC95 | 93 | 600 | 315 | 5.3 | 700-1000 |
| EC110 | 108 | 400 | 355 | 5.5 | 900-1200 |
